MF-01X Chassis – Compact 4WD At Home on a Range of Surfaces

Based around a tough monocoque frame with integrated gearboxes, this compact 4WD chassis gives a thrilling drive whether you take it on road or flat dirt surfaces. It features a rear-mounted motor, with gear-driven rear wheels and a propeller shaft taking power to the front. Both front and rear gearboxes have differential gears. The battery pack location in the chassis center secures excellent balance, while 4-wheel independent double wishbone suspension employs friction dampers. Off-road capable M-05Ra chassis uprights and hub carriers, plus rally block tires are also included.

Tamiya Escort MkII Rally (Pre Painted) (MF-01X) Specifications:

• Length: 397mm, Width: 163mm, Height: 151mm
• Wheelbase: 239mm (L)
• Tire Width/Diameter (Front & Rear): 26/60mm
• Tread (Front & Rear): 138mm
• Monocoque Frame
• Shaft-Driven 4WD
• 3-Bevel Differential Gears
• 2-Piece Steering Tie-Rod
• 4-Wheel Double Wishbone Suspension
• Front & Rear Friction Dampers
• Gear Ratio = 9.5:1
• 540 Motor
• Electronic Speed Controller Included

Tamiya Escort MkII Rally (Pre Painted) (MF-01X) Requires to Complete:

• 2 Channel Radio System
• 1 Servo
• Battery and Charger

Spec

• Brand: Tamiya
• Part No: HC-58687
• Barcode: 4950344066063
• Scale: 1:10
• Power Source: Electric – Brushed
• Surface Type: On Road
• Vehicle Type: Touring / Rally Car
• Build Level: Unassembled (Kit)
